PrimeShip-CAD Interface covers all of the information needed to perform the rule calculation of the current and harmonised CSR (Common Structural Rules) such as hull cross-sectional shapes, scantling and compartment data, longitudinal strength calculation results, etc. It effectively reduces data creation time and helps prevent input errors. On this page you will find a summary of the software, the software's hardware requirements, and information on how to apply for the software.
Overview of data linkage
* Data linkage performed using PrimeShip-CAD XML Schema Group.
PrimeShip-CAD XML Schema Group is a data structure file in XML format that has been developed in order to realize data linkage between the rule calculation software that ClassNK provides and commercial hull 2D/3D CAD or ship performance calculation software. The versatility of XML makes it possible to data-link among the various systems and it is widely used by numerous organizations and individuals.
PrimeShip-CAD Interface is comprised of the following interface programs:
* Implemented as a standard feature of the software
Overall Structure of Data Linkage
|OS||Windows XP/Vista/7/8/8.1 (32 or 64bit)|
|Memory||2GB or more recommended|
|Framework||Microsoft .NET Framework 4.0
(For Windows 7 OS and earlier)
Microsoft .NET Framework 4.5
(For Windows 8 OS)
|External applications (recommended)||Adobe Acrobat Reader 7.0 and later
Microsoft Excel 2003 and later
* Requires an environment where each piece of software used during data linkage is properly installed and operating.
Please click here to apply
Application Word for download
Applications and Inquiries
Hull Rules Development Department, NIPPON KAIJI KYOKAI
